3.2.Ground and Platform
A generator set can be placed on foundations like platform, soil, building or steel construction. The weight of the
generator set must not be more than the load carrying capacity of the ground.
It is recommended to build a concrete (strengthened with iron) platform for the generator set. Generally, the
platform is built at same horizontal sizes with the generator set and around 150-200 mm. thickness. A platform
built at a proper size depending on generator set size, will prevent the set from moving and reduce the negative
effects of vibration on engine.
If necessary, the platform can be constructed with such technical specifications that the floor is completely
insulated from the generator set against the negative effects of vibration.
If the generator set will be placed in such places that have the risk of flooding, then the thickness of the platform to
be built must be 300 mm. at least. This will ensure a dry and safe operation area for generator set and the people
working on it.
It is recommended to build standalone platforms for every single generator set. It also should be built separately
from any other building structures as other platforms, walls, etc..
3.3.Vibration
TEKSAN generator sets are designed for the minimum vibration transmission to the ground. For this purpose, rubber
vibration insulators are placed between the engine/alternator and the base frame. In applications with higher power
ratings, the insulators may be placed under the base frame for more efficiency in terms of vibration insulation.
If the generator set is placed on an upper floor, this vibration analysis of the generator and the base ground must be
done more carefully. In these types of applications, special insulation system designs may be needed with special
insulators. The base ground has to withstand the total weight of the generator set, and its accessories and the
negative effects of the uninsulated vibration.
Get the generator set fixed tightly to the ground or platform with steel connection bolts in order to prevent it from
moving around and giving damage to the electrical installation, fuel line, exhaust system, or any equipment around it.
3.4.Cooling and Ventilation
The heat radiated by engine can cause high temperature changes which can affect the performance of the generator
set.
The fresh air incoming, must be clean and cool as possible. Thus the performance and the lifetime of the engine
will be increased. This fresh air can be supplied directly from the installation area, but sometimes it may be
necessary to build ventilation channels and bring fresh air from outside.
Also ensure that the fan between the radiator and the engine can easily push out the hot air caused by the engine,
alternator or the radiator. This way the room can be ventilated and the generator set can be cooled efficiently.
At least two ventilation windows must be built for air intake and outlet. The fresh air intake window should be just
before the alternator and the hot air outlet window should be just after the radiator.
