3. Move the locking lever to the locked position. The status light should be a solid green.
4. To disconnect the TLP058 probe, move and hold the locking lever at the unlocked position and pull out the probe. Do not
pull on the ribbon cable while removing the probe.
Connect a BNC probe or cable by pushing it onto a channel BNC bayonet connector and turn the lock mechanism clockwise until
it locks.
NOTE. Connecting a probe does not automatically enable that channel (make it active). Use the instrument controls or
programmatic interface to turn on a channel and open its configuration menu to verify or change probe or cable settings
(bandwidth, attenuation, termination and so on).
Rackmount option information
An optional rackmount kit lets you install the oscilloscope in standard equipment racks. The rackmount kit requires seven rack
units (7U) of space to install.
Contact Tektronix Customer Support to purchase the RM4 rackmount kit option. Follow the instructions that come with the
rackmount kit (RM4 Rackmount Kit Instructions, Tektronix part number 071-3645-xx).
Make sure to allow at least two inches of clearance on the sides for air ventilation, and on the back for any cables you attach to
the rear panel.
Installing your instrument
6 MSO44, MSO46 Installation and Safety Manual
