PS2520 Series Performance Verification
8
Handheld and Benchtop Instruments Basic Service
Test Equipment
The performance verification procedures use external traceable test equipment to
directly check warranted characteristics. If you substitute equipment, always
choose instruments that meet or exceed the minimum requirements specified in
Table 6.
Alternative test equipment must meet or exceed the intended minimum
requirements. If you substitute equipment, you may need to modify the
performance verification procedures.
NOTE. Before beginning the performance verification procedures, warm up the
test equipment according to the manufacturer’s recommendations.
Table 6: Performance Verification Test Equipment
Description Minimum Requirements Example Product
Digital Multimeter (DMM)
500 V, 10 A, accuracy within ±0.01%
Fluke 8505A
Oscilloscope
20 MHz, 3% vertical deflection accuracy
Tektronix TDS300 Series
Electronic Load
40 V, 8 A CR mode
Variac
0 to 250 V, 2 A
Resistors
2.2 50 W, 27 100 W
Set Up
Following a 20 minute warm-up period, preset your power supply to the settings
listed in Table 7.
Table 7: Power Supply Initial Settings
Control Setting
(SHIFT) RECALL Enter 00 on keypad
AUTO SEQ OFF
(SHIFT) OUT 1
OCP OFF
(SHIFT) SERIES/INDEP INDEP
(SHIFT) PARA/INDEP INDEP
OUTPUT OFF
STEP SET (volts) 1
STEP SET (current) 0.1
