Command Groups
Table 2-34: Waveform Transfer Commands (cont.)
Command
Description
WFMOutpre:YMUlt? Returns the vertical scale factor per digitizing
level for the outgoing waveform
WFMOutpre:YOFf?
Returns the vertical position in digitizi n g
levels for the outgoing waveform
WFMOutpre:YUNit? Returns the vertical units for the outgoing
waveform
WFMOutpre:YZEro? Returns the vertical offset for the outgoing
waveform
For more
information, refer to Appendix B: Waveform Data in MSO/DPO2000B
and MSO/DPO2000 Series Instructions.(SeepageB-1.)
Zoom C om mand Group
Use the commands in the Zoom Command Group to expand and position the
waveform display horizontally and vertically, without changing the time base.
Table 2-35: Zoom Commands
Command
Description
ZOOm?
Returns the current horizontal positioning
and scaling of the display
ZOOm{:MODe|:STATE} Sets or returns the zoom mode
ZOOm:ZOOM1?
Returns the current horizontal positioning
and scaling of the display
ZOOm:ZOOM1:FA Ctor? Returns the zoom factor of a particular zoom
box
ZOOm:ZOOM1:HORizontal:POSition Sets or returns the horizontal zoom position
for the specified waveform in the specified
zoom
ZOOm:ZOOM1:HORizontal:SCAle Sets or returns the horizontal zoom scale of
the specified waveform in the specified zoom
ZOOm:ZOOM1:POSition Sets or returns the horizontal zoom position
for the specified waveform in the specified
zoom
ZOOm:ZOOM1:SCAle Sets or r eturns the horizontal zoom scale of
the specified waveform in the specified zoom
ZOOm:ZOOM1:STATE Specifies or returns a trace as zoomed, on
or off
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-57
