Installation
Quick Tips
Use the shortest possible ground lead and
signal path to minimize probe-induced ringing
and distortion on the measured s ignal.
Signal with a short ground lead
Signal with a l ong ground lead
Application Module Free Trial
A 30-day free tria l is available for all application m odules not installed in your oscillosco pe. The trial period begins when you power
on the oscilloscope for the first time.
After 30 days, you m ust purchase the module if you want to continue using the application. To see the date when your free trial
period expires, push the front panel Utility b utton, p ush th e lower-bezel Utili ty P age button, use multipurpose knob a to select
Config, and push the lower-bezel Abou t button.
24 DPO3000 Series Oscilloscopes User Ma nual
