Trigger Setup
For FlexRay, triggering occurs when the user-selected data input matches the data and qualifier in the signa l starting at the
byte o ffset. Set the number of bytes to m atch the number of bytes of inte rest. Use the data qualifier to perform: =, !=, <, >, >=,
and <= operations. Triggering on identifier and data always matches the identifier and data selected by the user, with the
data starting at the first byte. No rolling window is used.
RS-232 Bus Trigger Data Matching
You can trigger on a specific data value for RS-232 bytes. If you defined an end-of-packet character to use f or RS-232 bus
decoding, you can use the same end-of-packet character as a data value for trigger data matching. To do so, choose the Tx End of
Packet or the Rx End of Packet character as the Trigger On se lection.
Parallel Bus Trigger Data Matching
Optimum parallel bus trigger performance is achieved by using only analog channels or only digital cha nnels (MSO4000 Series only).
MSO4000 and DPO4000 Series Oscilloscopes User Manual 155
