Preface
Preface
This manual describes the installation and operation of the following oscilloscopes:
DPO4104 DPO4054 DPO4034 DPO4032
MSO4104 MSO4054 MSO4034 MSO4032
Key Features
MSO4000 and DPO4000 Series instruments can help you verify, debug, and characterize electronic designs. Ke y features include:
1 GHz, 500 MHz, and 350 MHz bandwidths
2 a nd 4 channel models
Sample rates up to 5 GS/s on all analog channels
10 M points record len gth on all channels
50,000 waveforms/second d isp lay rate
I
2
C, SP I, CAN, LIN, FlexRay, RS-232, RS-422, RS-485, UART, I
2
S, Left Justified (LJ), Right Justified (RJ), TDM bus triggering
and analysis (with the a ppropriate application module and model oscilloscope)
Power analysis application module (optional)
Wave Inspector controls for mana ging long record lengths, with zoom a nd pan, play and pause, search and mark
10.4 inch (264 mm) X GA color display
Small and lightweight, a t 5.5 inches (140 mm) deep and 11 pounds (5 kg)
xvi MSO4000 and DPO4000 S eries Oscilloscopes User Manual
