Installation
Installing an Application Module
CAUTION. To avoid dama ge to the oscilloscope or application module, observe ESD (electrostatic discharge) p recautions.
(See page 16, Powering On the Oscilloscope.)
Turn off the oscilloscope power while removing or adding an application module.
(See page 19, Powering Off the Oscilloscope.)
Optional application module packages extend the capability of your oscilloscope . You can install up to fo ur application modules at
one time. App lication modules go into the two slots with windows in the upper right corner of the front panel. Two additional slots
are directly behind the two that you can see. To use these slots, install the module with the label facing away f rom you.
Refer to the Tektronix 4000 S eries Oscillosco pes Application Module Installation Instructions that came with your application modu le
for instructions on installing and testing an application module.
NOTE. If you remove an application module, the features provided by the application module become unavailable. To restore the
features, turn off the oscilloscope power, reinstall the module and turn on the oscilloscope power.
26 MSO4000 and DPO4000 S eries Oscilloscopes User Manual
