Installation
Quick Tips
Use the shortest possible ground lead and
signal path to minimize probe-ind uced ringing
and distortion on the measured signal.
Signal with a short ground l ead
Signal with a long ground lead
Application Module Free Trial
A 30-da y free trial is available for all application modules not installed in your oscilloscope. The trial period begins when you power
on the oscilloscope for the first time.
After 30 days, you must purchase the module if you want to co ntinue using the application. To see the date when your free trial
period expires, push the front panel Utilit y bu tton, push the lower-bezel Utility Page button, use multipurpose knob a to select
Config, and push the lower-bezel Abou t button.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 25
