Start or reset a mask test
From the Mask menu, select Pass/Fail Results.
Overview. Use these controls to start a test or reset the test to the starting point.
To use.
■
Click the On/Off control to start the test.
■
Click the Reset control to reset the test to the beginning.
Behavior. When the test starts, it uses the parameters in the Pass/Fail Test Setup control window. When the test is reset, the
Total Hits, Failed Wfms, Hits per segment, and Waveform Tested fields are reset to zero.
What do you want to do next?
Learn about test summary.
Learn about hits per segment.
Learn about the Mask Test Controls window.
Learn about test results.
User mask setup
Set the user mask controls
From the Mask menu, select Mask Setup; then open the Masks tab and click the User Mask button.
Mask testing setups
236 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
