TIP. For information on measurement algorithms, refer to the Automatic Measurement Algorithms and Methods for High-

Performance Communications Applications application note, 85w_15763.pdf. This application note is available from the

www.tektronix.com Web site.

What do you want to do next?

Return to the Measurement control window overview.

Measurement setup control window (Amplitude tab)

From the Measure menu, select Measurement Setup; then open the Ampl tab.

Overview

Use this control window to set up the instrument for taking automatic amplitude measurements.

To use

For information on the controls, click the buttons.

■

Measurements

■

Channel

■

Measure | Source

■

Ref Levels

■

Gating

■

Statistics

■

Snapshot

■

Histogram

Measurement setups
