Tektronix TDS 420A Service Manual

Options and Accessories
TDS 420A, TDS 430A & TDS 460A Service Manual
7-3
Optional Accessories
You can also order the optional accessories listed in Table 7--3:
Table 7- 3: Optional Accessories
Accessory Part Number
Front Cover 200-3232-00
Service Manual 070-9703-XX
Printed Programm er Manual 070-9876-XX
Video Clamp 013-0278-00
Current Probe/Calibrator TCP202
High Volt age Differential Probe P5205
High Volt age Differential Probe P5200
Analog Differential Amplifier ADA400A
Plotter (GPIB and Centronics Standard) HC100
Plotter (Centronics Standard) HC200
Oscilloscope Cart K212
Oscilloscope Camera C9
Oscilloscope Camera Adapter 016-1154-00
Soft-Sided Carrying Case 016-1158-01
Transit Case 016-1157-00
GPIB Cable (1 meter) 012-0991-01
GPIB Cable (2 meter) 012-0991-00
Printer Pack with Seiko DPU-411 printer and accessory pouch TDS4F5P
Pouch (includes mount ing plate) 016-1159-00
VGA Cable (Required to meet all emissions specifications) CTL3VGAMM-5
(LCOM part number)
Table 7--4 lists compatible probes recommended for use with your digitizing
oscilloscope:
Table 7- 4: Compatible Probes
Probe Type Tektronix Model Description
Passive, high impedance voltage P6138A
P6101B
10X, 400 MHz
1X, 15 MHz
Passive, SMD P6563A 20X, 500 MHz
