TDS2CMA Communications Module
144
TDS1000/2000-Series Digital Oscilloscope User Manual
H Connect the oscilloscope to the GPIB network. Use an appropri-
ate GPIB cable. You can stack cable connectors. T he next t able
lists cables that you can order to connect the oscilloscope to the
GPIB network.
Cable type
Tektronix part number
GPIB, 6.6 feet (2 meters) 012-0991-00
GPIB, 3.3 feet (1 meter) 012-0991-01
H Assign a unique device address to the oscilloscope. No two
devices can share the same device address. The GPIB Settings
information describes how to set the oscilloscope GPIB interface.
H Power on at least two-thirds of the GPIB devices while using the
network.
GPIB Settings
To set the oscilloscope GPIB interface, follow these steps:
1. If you have not done so yet, connect the oscilloscope to the GPIB
network.
