Maintenance
Rear Case
You will need a t
orque-limiting Torx T-15 screwdriver and pliers for this
procedure.
Refer to the ex
ploded view diagram. (See page 96. )
Removal.
1. Remove the p
ower button . (See page 57, Pow er Button.)
2. Place the oscilloscope face down on a so ft surface such as an anti-static mat.
3. Remove the two ESD protection covers from the rear case to expose two
screws.
4. Remove the five screws located on the rear case. Lift the handle to access the
top two screws.
5. Lift the rear case off of the oscilloscope.
Instal
lation.
1. Place the oscilloscope face down on a soft surface (such as an anti-static mat).
CAUTION. Be careful not to pinch any wires or other parts between the front
and re
ar cases.
2. Place the rear case onto the assem bled oscilloscope and verify that:
All of the edges align with the front case.
The Li-ION battery is vertical in the battery location.
The slots a
lign near the USB co nn ector and near the battery.
CAUTION. Avoid cross-threading the screws that attach the rear case to the front
case. An easy way to avoid this is to slip the screw into the hole and, using slight
pressure, slowly rotate the screw counterclockwise until you feel the screw slip
into the screw threads. Then tighten the screw clockwise. A properly started screw
will exhibit very little re sistance going in.
3. Install the five screws in the rear case. Tilt the handle to a ccess the top two
holes.
4. Install the two ESD protection covers.
5. Install the power button. (See pa ge 57, Power Button.)
58 TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
