Teldat 4Ge User Manual

;
event
; -- ELS Config --
enable trace subsystem DHCPC ALL
enable trace subsystem DHCP ALL
exit
;
;
protocol ip
; -- Internet protocol user configuration --
rule 1 local-ip ethernet0/1.463 remote-ip any
rule 1 napt translation
rule 1 napt firewall
;
classless
exit
;
protocol dhcp
; -- DHCP Configuration --
Server
; -- DHCP Server Configuration --
enable
;
;
subnet 4Ge 0 network 1.1.1.0 255.255.255.0
;
host 4Ge 0 fixed-ip 1.1.1.2
host 4Ge 0 client-id asc teldat
host 4Ge 0 router 1.1.1.1
host 4Ge 0 subnet-mask 255.255.255.0
host 4Ge 0 option 43 asc
antenna&apn=internet.es&pin=1844&ntps=192.168.212.14&usr=internet&pwd=internet
;
exit
;
exit
;
dump-command-errors
end
3.2.1 DHCP
Just like Cisco routers, Teldat routers can act as the DHCP server for the Teldat 4Ge. We use this protocol to config-
ure certain parameters in the Teldat 4Ge (such as the SIM PIN number and the WWAN mobile network APN).
; -- DHCP Configuration --
server
; -- DHCP Server Configuration --
enable
;
;
subnet 4Ge 0 network 1.1.1.0 255.255.255.0
;
host 4Ge 0 fixed-ip 1.1.1.2
host 4Ge 0 client-id asc teldat
host 4Ge 0 router 1.1.1.1
host 4Ge 0 subnet-mask 255.255.255.0
host 4Ge 0 option 43 asc
antenna&apn=internet.es&pin=1844&ntps=192.168.212.14&usr=internet&pwd=internet
;
exit
;
exit
The router option assigns a default route to the Teldat 4Ge. This route is necessary if, for example, the Teldat 4Ge
and the TFTP server are in different networks.
Teldat S.A.
3 Configuration
Teldat 4Ge 11

Teldat 4Ge Specifications

General

WAN Ports	1
LAN Ports	4
Cellular	4G LTE
SIM Slots	1
Wi-Fi Standards	802.11b/g/n
Device Type	Router
Wireless Technology	Wi-Fi
Ethernet Ports	4
Security Features	Firewall, VPN

Summary

Legal Notice

Warranty

Details warranty terms and disclaimers for the publication.

About This Guide

Supported Devices

Specifies the Teldat 4Ge router as the sole subject of this guide.

Who Should Read This Manual?

Identifies target audience as support personnel for configuration and monitoring.

When Should This Manual Be Read?

Recommends reading upon readiness to familiarize with the device and components.

What Is In This Manual?

Outlines the manual's content, including description, scenarios, interfaces, features, configuration, and monitoring.

What Cannot Be Found In This Manual?

Clarifies that hardware information is not included; refers to installation manuals.

How Is The Information Organized?

Explains that each chapter covers a specific aspect of the device for user knowledge.

Technical Support

Provides contact information and details on the technical support service offered by Teldat S.A.

Related Documents

Lists other relevant documents for further technical information and protocols.

Introduction

Description of the Device

Details the Teldat 4Ge's function, technology, and power sources for routing corporate data.

Application Scenarios

Presents two primary use cases: network coverage issues and backup for existing routers.

Device Interfaces and Connection

Explains the WWAN and Ethernet interfaces and two methods for connecting to a corporate router.

Operating Features

Describes how the device operates using the DHCP protocol for IP address assignment and configuration.

Configuration

Configuring a Cisco Router

Provides a guideline for connecting a Cisco router to a WWAN mobile network via Teldat 4Ge.

DHCP Configuration for Cisco

Details the Cisco router's role as a DHCP server and parameters for Teldat 4Ge configuration.

Configuring a Teldat Router

Offers a guideline for configuring Teldat routers to connect to the Teldat 4Ge via VLAN 463.

DHCP Configuration for Teldat

Explains how Teldat routers can act as DHCP servers for the Teldat 4Ge, specifying parameters.

Monitoring via the Console

4.1 WWAN Monitoring

Guides on accessing and using the monitoring console for the 4G module and WWAN interface.
