Tenda A301 User Manual

51
4.7.2 Switch the extender from the AP mode to the repeater
mode
Configurations (except SSID and WiFi password you set) will be cleared when you switch
from AP mode to Repeater mode.
Configuration procedure:
Step 1 Choose Operating Mode to enter the configuration page.
Step 2 Click Repeater Mode.
Step 3 Click Switch Mode.
Step 4 Click OK on the page.
Step 5 Wait until the progress bar is complete. Then reconfigure it to extend your existing WiFi
network.
---End

Tenda A301 Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
RJ-45 ports quantity (transmitter)	1
Output current	0.7 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	-40 - 70 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, FCC
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	55 mm
Height	39 mm
