Tenda A301 User Manual

54
4.10 Reset the extender
If you are uncertain about why the internet is inaccessible through the extender or you forget the
login password of the extender, you can reset the router.
Resetting the extender clears all configurations. You need to configure the extender again.
4.10.1 Reset the extender with Web UI
Step 1 To enter the configuration page, choose Administration.
Step 2 Click Reset.
Step 3 Click Reset to continue.
---- End
Wait for the extender complete resetting. Then configure it again.
4.10.2 Reset the extender with the RESET button
With the PWR LED indicator of the extender solid on, hold the RESET button down with a pin.
Then release it when the all LED indicators blink once then turn off. When the PWR LED indicator
turns solid on again, the extender is restored to factory settings successfully.

Tenda A301 Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
RJ-45 ports quantity (transmitter)	1
Output current	0.7 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	-40 - 70 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, FCC
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	55 mm
Height	39 mm
