Enable: Check or uncheck to enable or disable the remote
web-based management feature.
Port: Enter a port number for remote web-based
management.
IP Address: Enter the IP address of a PC on Internet
authorized to access and manage the device’s web-based
utility remotely.
Note:
If you enter 0.0.0.0 in the IP address box, then all PCs on
Internet can access your router’s Web-based utility to view or
change your settings remotely once you enable the remote
Web-based management feature.
For example: If you want to allow only a PC at the IP address of
218.88.93.33 to access your router’s web-based utility from
Internet via port: 8080, then config same settings shown on the
screenshot above on your device. And what this IP user needs
to do is to simply launch a browser and enter http:
//220.135.211.56:8080 (provided that the router’s WAN IP
address is 220.135.211.56).
