Tenda AC15 User Manual

18
Customize your WiFi name, password, and login password, then click Next to continue.
Tips
1. Note that the WiFi password is used to connect to your wireless network (WiFi) while the login
password is for logging in to the Router’s User Interface. You can check the option in front of Set
up the login password to the same as the WiFi password to set them to the same. Or uncheck it
to set them to different ones respectively.
2. The Router provides two types of frequency bands: 2.4GHz and 5GHz. 5GHz WiFi name can
only be searched by 5GHz available wireless devices.
When you click the Next button in the page below, the 5GHz WiFi name will be changed into the
same one as that of 2.4GHz WiFi name except the suffix “_5G”, for example, the 2.4GHz WiFi
name is Tenda_000118, the 5GHz WiFi name will be Tenda_000118_5G.
When the following page appears, it indicates that you can access the Internet now. If you want
to experience more features, click Advanced, type login password you set up just now, and
click Login to log in to the Router’s user Interface.

Tenda AC15 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Bandwidth (first)	5 GHz
Bandwidth (second)	2.4 GHz
Mobile network connection	No
WLAN data transfer rates supported	600, 1300 Mbit/s
Antenna gain level (max)	3 dBi
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Routing protocols	IP
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, C-tick, IC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	76.6 mm
Width	226 mm
Height	179.5 mm
Weight	1210 g
