Tenda AC15 User Manual

45
 Click Save.
Wireless Repeating
The Router can act as a wireless repeater to extend wireless signal. The wireless repeater can have
wired and wireless clients, and access the Internet when it connects to the wireless base station. There
are two types of Wireless Repeating: WISP and Universal repeater. When the Router works under
WISP mode, it assigns IP addresses to its clients by itself. And the clients obtain IP addresses from
the base station the Router bridges when the Router works under Universal repeater mode. You can
select WISP OR Universal repeater to extend your wireless network.
You need two routers: one set up as a Router which acts as a base station, and the other set up as a
bridge.
Example
You can install the first Router (Router A) in a room that located on the first floor which has your
Internet connection, then set up the second Router (Router B) in bridge modes. And place the Router
B in a different room that has your home entertainment center which located on the second floor.
Connect the second Router (Router B) in bridge mode to your computer, game console, and etc.
Wireless Router
Wireless Router in Bridge Mode

Tenda AC15 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Bandwidth (first)	5 GHz
Bandwidth (second)	2.4 GHz
Mobile network connection	No
WLAN data transfer rates supported	600, 1300 Mbit/s
Antenna gain level (max)	3 dBi
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Routing protocols	IP
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, C-tick, IC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	76.6 mm
Width	226 mm
Height	179.5 mm
Weight	1210 g
