Tenda AC21 User Manual

152
12.2 DHCP reservation
12.2.1 Overview
Through the DHCP reservation function, specified clients can always obtain the same IP address
when connecting to the router, ensuring that the router's "Virtual server", "DDNS", "DMZ host"
and other functions can function normally. This function takes effect only when the DHCP server
function of the router is enabled.
To access the configuration page, log in to the web UI of the router, and choose System Settings >
DHCP Reservation.
Parameter description
Parameter
Description
Device Name
It specifies the device name of the client.
MAC Address
It specifies the MAC address of the client.
IP Address
It specifies the IP address reserved for the client.
Status
It specifies whether the client is online or not.
Operation
The available options include:
⚫
: It is used to add a new DHCP reservation rule.
⚫
: It is used to bind the MAC address to the reserved IP address.
⚫
: It is used to unbind the MAC address from the reserved IP address.
⚫
: It is used to delete the DHCP reservation rule.
12.2.2 Assign static IP addresses to LAN clients
Scenario: You have set up a FTP server within your LAN.
Goal: Assign a fixed IP address to the host of the FTP server and prevent the failure of access to the
FTP server owing to the change of IP address.
Solution: You can configure the DHCP reservation function to reach the goal.
Assume that the information of the FTP server includes:
− The fixed IP address for the server: 192.168.0.136
− MAC address of the FTP server host: D4:61:DA:1B:CD:89

Tenda AC21 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	6
Antenna gain level (max)	6 dBi
Cables included	LAN (RJ-45)
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	150.6 mm
Width	231.3 mm
Height	39.6 mm
