clear the VCCA OV and UV masks which are set in the static configurations, Table 5-8. After these instructions
are executed the PMICs wait for a valid ON Request before entering the ACTIVE state. The definition for each
power state is described below:
STANDBY The PMICs are powered by a valid supply on the system power rail (VCCA > VCCA_UV). All
device resources are powered down in the STANDBY state. EN_DRV is forced low in this state.
The processor is in the Off state, no voltage domains are energized. Refer to the Section 6.3.2
sequence description.
The STANDBY state is also entered when an error occurs and the PMIC transitions out of the
PFSM mission states and into the FSM states. When the device returns from the FSM state
the to PFSM the first state is represented by STANDBY with all of the resources powered down
and EN_DRV forced low. The sequence Section 6.3.1 is performed before the PMIC leaves the
PFSM and enters the FSM state SAFE_RECOVERY.
ACTIVE The PMICs are powered by a valid supply. The PMICs are fully functional and supply power
to all PDN loads. The processor has completed a recommended power up sequence with all
voltage domains energized in both MCU and Main processor sections. Refer to the Section
6.3.8 sequence description.
MCU_ONLY The PMICs are powered by a valid supply. Only the power resources assigned to the MCU
Safety Island are on. Refer to the Section 6.3.7 sequence description.
Pwr SoC
Error
The PMICs are powered by a valid supply. Only the power resources assigned to the MCU
Safety Island are on. Refer to the Section 6.3.5 sequence description. The only active trigger is
'B', requiring the PMICs to return to the MCU_ONLY mode. The return to MCU_ONLY mode
and eventually ACTIVE mode is only recommended after the interrupts which caused the
SOC_PWR_ERROR have been cleared.
Retention The PMICs are powered by a valid supply. When the PMICs I2C_7 triggers are set (DDR
Retention), only 3 SoC voltage domains (vdds_ddr_bias, vdds_ddr, and vdds_ddr_c) remain
energized while all other domains are off to minimize total system power. EN_DRV is forced low
in this state. Refer to the Section 6.3.9 sequence description.
6.2 PFSM Triggers
As shown in Figure 6-1, there are various triggers that can enable a state transition between configured states.
Table 6-1 describes each trigger and its associated state transition from highest priority (Immediate Shutdown)
to lowest priority (I2C_3). Active triggers of higher priority block triggers of lower priority and the associated
sequence.
Table 6-1. State Transition Triggers
Trigger Priority (ID)
Immediate
(IMM)
REENTERANT PFSM Current State
PFSM
Destination
State
Power Sequence or
Function Executed
Immediate
Shutdown
(9)
0 True False
STANDBY, ACTIVE,
MCU ONLY, Suspend-
to-RAM
SAFE
(1)
TO_SAFE_SEVERE
MCU Power Error 1 True False
STANDBY, ACTIVE,
MCU ONLY, Suspend-
to-RAM
SAFE
(1)
TO_SAFE
Orderly
Shutdown
(9)
2 True False
STANDBY, ACTIVE,
MCU ONLY, Suspend-
to-RAM
SAFE
(1)
TO_SAFE_ORDERLY
OFF Request 4
(11)
False False
STANDBY, ACTIVE,
MCU ONLY, Suspend-
to-RAM
STANDBY
(2)
TO_STANDBY
WDOG Error 5 False True ACTIVE ACTIVE
ACTIVE_TO_WARM
ESM MCU Error 6 False True ACTIVE ACTIVE
ESM SOC Error 7 False True ACTIVE ACTIVE ESM_SOC_ERROR
WDOG Error 8 False True MCU ONLY MCU ONLY MCU_TO_WARM
ESM MCU Error 9 False True MCU ONLY MCU ONLY
www.ti.com Pre-Configurable Finite State Machine (PFSM) Settings
SLVUC99 – JANUARY 2022
Submit Document Feedback
Optimized Dual TPS6594-Q1 PMIC User Guide for Jacinto
™
7 DRA829 or
TDA4VM Automotive PDN-0C
33
Copyright © 2022 Texas Instruments Incorporated
