Texecom Impaq SC-W User Manual

INS876-1 14/15
6.0 Specifications
Specifications
Alarm System
EN50131-2-8:2017, EN50131-2-6:2008,
EN50131-5-3:2017, EN50131:2006+A2:2017,
PD6662:2017, Grade 2 Class II
Product Type & Frequency Band
GJAA1000 868.2 – 868.4MHz
GJAA2000 866.2 – 866.4MHz (Not CE approved)
GJAA3000 433.3 – 433.7MHz
Receiver Category 1, Class 2
Receiver LBT Listen Before Talk
Transmitter Duty Cycle <1%
Max RF Power 10mW
Low Voltage Signal 2.50V
Operating Voltage 3V
Maximum Current 12mA
Quiescent Current 19μA
Relative Humidity 0 - 95% non-condensing
Operating Temperature -10°C to 55°C
Weight 80g
Dimensions
130mm x 26mm x 25mm (magnet 57mm x
11.5mm)
7.0 Legal Information
Supplier: Texecom Ltd, Haslingden, Lancashire, BB4 4PW, UK.
Made in England
WEEE Directive: 2012/19/EU (WEEE Directive): Products marked with this symbol
