Thermo King CSR-40SL-126 User Manual

CSR-20 & CSR-40, September 1999
Unit Description Unit Illustrations 2-5
Typical Unit Front View
1. Evaporator Access Door, 1018 mm (40.08 in.) Wide with Two Latches — Models with Two Evaporator Fans
2. Evaporator Access Door, 1399 mm (55.04 in.) Wide with Three Latches — Models with Three Evaporator Fans
3. Heater Access Panel Location
4. Condenser Fan
5. Compressor Compartment
6. Supply Air Sensor Probe Holder
7. Power Cord Storage Compartment
8. Control Box
9. USDA Receptacle Panel (Access from Inside Container)
10. Fresh Air Exchange Vent
10
9
8
7
1
2
3
4
5
6

Thermo King CSR-40SL-126 Specifications

General

Brand	Thermo King
Model	CSR-40SL-126
Category	Heat Pump
Language	English
