CSR-20 & CSR-40, September 1999
Unit Description Unit Illustrations 2-19
1
2
3
4
5
Typical Unit Back View
1. Evaporator Grille
2. Unit Gasket
3. Top Rear Plate
4. Bottom Rear Plate
5. Sensor Connector Assembly:
• Controller Communications and Data Download Port
• Cargo (Pulp) Sensor Connection
• USDA1 Sensor Connection
• USDA2 Sensor Connection
• USDA3 Sensor Connection
