Fuel Shut-Off Valve
T he fuel shut-off v alv e ( Figure 14 ) is located on
left front of engine . V alv e has tw o positions:
Closed and Open. Mo v e lev er to closed position
when storing or transpor ting mac hine . Open v alv e
before star ting engine .
Recoil Starter
Pull recoil star ter handle ( Figure 15 ) to star t engine .
Figure 15
1. Recoil starter
3. Hour meter
2. On/off switch
On/Off Switch
T he on/off switc h ( Figure 15 ) is located on rear
of engine . Mo v e switc h to On position to star t
engine and Off to stop engine .
Hour Meter
T he hour meter ( Figure 15 ) located on rear of
engine , indicates the total hours of mac hine
operation.
Kickstand
T he kic kstand ( Figure 16 ) is mounted to rear of
mac hine and is used to raise rear of mac hine for
installation or remo v al of transpor t wheels .
Figure 16
1. Kick stand
