g007627

Figure40

1.Service/parkingbrake

cable

2.Frontjamnut

5.Closethecoverandsecuretheretainer.

BeltMaintenance

AdjustingtheBelts

Ensurethatthebeltsareproperlytensionedto

ensureproperoperationofthemachineandprevent

unnecessarywear.Checkthebeltsfrequently.

AdjustingtheReel-DriveBelt

1.Removethebelt-covermountingfastenersand

thebeltcovertoexposethebelt(Figure41).

g007618

Figure41

1.Beltcover

2.Checkthetensionbypressingthebeltat

mid-spanofthepulleys(Figure42)with18to

22N(4to5lb)offorce.Thebeltshoulddeect

6mm(1/4inch).

g007619

Figure42

1.Reel-drivebelt2.Idlerpulley

3.Completethefollowingstepstoadjustthebelt

tension:

A.Loosentheidler-pulleymountingnutand

pivottheidlerpulleyclockwiseagainstthe

backsideofthebeltuntilyouattainthe

desiredbelttension(Figure42).
