g007625
Figure48
1.Differentialcoversections
3.Rightrearbearinghousing
2.Frontclutchhousing
5.Loosentheidlerpulleymountingnutonthe
differentialidlerpulleyandpivottheidlerpulley
counterclockwiseawayfromthebacksideofthe
belttoreleasethebelttension.
6.Removethe2boltsand2locknutsthatsecure
thefrontclutchhousingtothesideplate(Figure
48).
7.Rotatethehousing180°sothatthebottomof
thehousingpointsupward.
8.Removethe2boltsand2locknutsthatsecure
therightrearbearinghousingtothesideplate
(Figure48).
9.Rotatethehousing180°sothatthebottomof
thehousingpointsupward.
10.Removetheoldbelt.
11.Slidethenewbeltovertherotatedhousing
covers,thedifferentialcoversections,andonto
thedifferentialpulleys.
12.Ensurethattheidlerpulleyispositionedagainst
thebacksideofthebelt.
13.Rotatebothhousingsbackintotheupright
positionandsecurethemtothesideplatewith
theboltsandnutsthatyoupreviouslyremoved.
14.Adjustthedifferentialbelttension;referto
AdjustingtheDifferentialBelt(page33).
15.Adjustthebelttensiononthetractiondrive
andreel-drivebelts;refertoAdjustingthe
Traction-DriveBelt(page33),andAdjustingthe
Reel-DriveBelt(page32).
16.Installthedifferential,tractiondrive,and
reel-drivecovers.
ControlsSystem
Maintenance
AdjustingtheTraction
Control
Ifthetractioncontroldoesnotengageoritslipsduring
operation,anadjustmentisnecessary.
1.MovethetractioncontroltotheDISENGAGED
position.
2.LoosentheretainerthatsecurestheV-beltcover
andpivotthecoveropen(Figure46).
3.T oincreasethecabletension,loosenthe
front-cablejamnutandtightentheback-cable
jamnut(Figure49)untilaforceof8to9N·m(6
to7lb)iscreatedtoengagethetractioncontrol.
Note:Measuretheforceatthecontrolknob.
g027907
Figure49
1.Tractioncable3.Back-cablejamnut
2.Front-cablejamnut
4.Tightenthefront-cablejamnut.
5.Closethecoverandsecuretheretainer.
6.Checkthetraction-controloperation.
35
