Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
Interval
MaintenanceProcedure
Beforeeachuseordaily
•Checktheengine-oillevelandaddoilasneeded.
•Ensurethattheengineshutsoffwithin3secondsafterreleasingtheblade-control
bar.
Aftereachuse
•Cleangrassclippingsanddirtfromunderthemachine.
Every25hours
•Servicetheairlter;serviceitmorefrequentlyindustyoperatingconditions.
•Chargethebattery(ifequipped)for24hours.
Yearly
•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.
•Changetheengineoil.
•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).
•Cleantheenginebyremovingdirtanddebrisfromitstopandsides;cleanitmore
frequentlyindustyoperatingconditions.
Yearlyorbeforestorage
•Emptythefueltankbeforerepairsasdirectedandbeforeyearlystorage.
Important:Refertoyourengineowner’smanualforadditionalmaintenanceprocedures.
MaintenanceSafety
•Disconnectthespark-plugwirefromthespark
plugandremovetheelectric-startbuttonbefore
performinganymaintenanceprocedure.
•Wearglovesandeyeprotectionwhenservicing
themachine.
•Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.Weargloveswhen
servicingtheblade.Donotrepairoralterthe
blade(s).
•Nevertamperwithsafetydevices.Checktheir
properoperationregularly.
•Tippingthemachinemaycausethefueltoleak.
Fuelisammableandexplosive,andcancause
personalinjury.Runtheenginedrytoremovethe
fuelwithahandpump;neversiphonthefuel.
•Toensureoptimumperformanceandcontinued
safetycerticationofthemachine,useonly
genuineT ororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadeby
othermanufacturerscouldbedangerous,and
suchusecouldvoidtheproductwarranty.
PreparingforMaintenance
1.Shutofftheengine,removetheelectric-start
button(ifequipped),andwaitforallmoving
partstostop.
2.Disconnectthespark-plugwirefromthespark
plug(Figure25).
g032617
Figure25
1.Spark-plugwire
3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.
Important:Beforetippingthemachineto
changetheoilorreplacetheblade,allowthe
fueltanktorundrythroughnormalusage.If
youmusttipthemachinepriortorunning
outoffuel,useahandfuelpumptoremove
thefuel.Alwaystipthemachineontoits
side,withthedipstickdown.
ServicingtheAirFilter
ServiceInterval:Every25hours
Yearly
22

Toro 20334 Specifications

General

Brand	Toro
Model	20334
Category	Lawn Mower
Power Source	Gasoline
Engine	Briggs & Stratton
Engine Displacement	163 cc
Engine Type	4-Cycle
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Deck Material	Steel
Weight	80 lbs
Start Type	Recoil
Oil Capacity	20 oz
Cutting Width	22 inches
Drive System	Rear-Wheel Drive
Fuel Capacity	1.0 quart
Wheel Size	10 inches rear
Warranty	2-Year Full Warranty
Cutting Height	1.0 to 4.0 inches
