AdjustingtheSelf-Propel
Drive
Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrive.
1.Turntheadjustmentknobcounterclockwiseto
loosenthecableadjustment(Figure34).
g027231
Figure34
1.Handle(leftside)
4.Turntheknobclockwiseto
tightentheadjustment.
2.Adjustmentknob5.Turntheknob
counterclockwiseto
loosentheadjustment.
3.Self-propel-drivecable
2.Adjustthetensiononthecable(Figure34)by
pullingitbackorpushingitforwardandholding
thatposition.
Note:Pushthecabletowardtheengineto
increasethetraction;pullthecableawayfrom
theenginetodecreasethetraction.
3.Turntheadjustmentknobclockwisetotighten
thecableadjustment.
Note:Tightentheknobrmlybyhand.
Storage
Storethemachineinacool,clean,dryplace.
PreparingtheMachinefor
Storage
1.Onthelastrefuelingoftheyear,addfuel
stabilizer(suchasToroPremiumFuel
Treatment)tothefuelasdirectedonthelabel.
2.Disposeofanyunusedfuelproperly.Recycle
itaccordingtolocalcodesoruseitinyour
automobile.
Note:Oldfuelinthefueltankistheleading
causeofhardstarting.Donotstorefuelwithout
fuelstabilizermorethan30days,anddonot
storestabilizedfuelmorethan90days.
3.Runthemachineuntiltheengineshutsofffrom
runningoutoffuel.
4.Starttheengineagainandallowittorununtil
itshutsoff.Whenyoucannolongerstartthe
engine,itissufcientlydry.
5.Disconnectthewirefromthesparkplugand
connectthewiretotheretainingpost(if
equipped)andremovetheelectric-startbutton
(ifequipped).
6.Removethesparkplug,add30ml(1oz)of
engineoilthroughthespark-plughole,andpull
therecoil-starterropeslowlyseveraltimesto
distributeoilthroughoutthecylindertoprevent
cylindercorrosionduringtheoff-season.
7.Looselyinstallthesparkplug.
8.Tightenallnuts,bolts,andscrews.
9.Electric-startmodelsonly:Chargethebattery
for24hours,thenunplugthebatterycharger
andstorethemachineinanunheatedarea.If
youmuststorethemachineinaheatedarea,
youmustchargethebatteryevery90days.
RefertoChargingtheBattery(page24).
RemovingtheMachine
fromStorage
1.Electric-startmodelsonly:Chargethebattery
for24hours;referto4ChargingtheBattery
(page8).
2.Checkandtightenallfasteners.
3.Removethesparkplugandspintheengine
rapidlybypullingtherecoil-starthandletoblow
theexcessoilfromthecylinder.
4.Installthesparkplugandtightenitwithatorque
wrenchto20N∙m(15ft-lb).
27

Toro 20334 Specifications

General

Brand	Toro
Model	20334
Category	Lawn Mower
Power Source	Gasoline
Engine	Briggs & Stratton
Engine Displacement	163 cc
Engine Type	4-Cycle
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Deck Material	Steel
Weight	80 lbs
Start Type	Recoil
Oil Capacity	20 oz
Cutting Width	22 inches
Drive System	Rear-Wheel Drive
Fuel Capacity	1.0 quart
Wheel Size	10 inches rear
Warranty	2-Year Full Warranty
Cutting Height	1.0 to 4.0 inches
