1.Unclipthetopoftheair-ltercover(Figure26).
g033493
Figure26
1.Clip3.Airlter
2.Air-ltercover
2.Removetheairlter(Figure26).
3.Inspecttheairlter.
Note:Iftheairlterisexcessivelydirty,replace
itwithanewlter.Otherwise,gentlytaptheair
lteronahardsurfacetoloosendebris.
4.Installtheairlter.
5.Usethecliptoinstalltheair-ltercover.
ChangingtheEngineOil
ServiceInterval:Yearly
Changingtheengineoilisnotrequired,butif
youwanttochangetheoil,usethefollowing
procedure.
Note:Runtheengineafewminutesbeforechanging
theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.
EngineOilSpecications
Engineoilcapacity
0.44L(15oz)
OilviscositySAE30orSAE10W-30
detergentoil
APIserviceclassicationSJorhigher
1.Movethemachinetoalevelsurface.
2.RefertoPreparingforMaintenance(page22).
3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure27).
g033377
Figure27
1.Dipstick3.Full
2.Add
4.Tipthemachineontoitsside(sothattheair
lterisup)todraintheusedoilfromtheoil-ll
tube(Figure28).
g032618
Figure28
5.Afterdrainingtheusedoil,returnthemachineto
theoperatingposition.
6.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.
7.Wait3minutesfortheoiltosettleintheengine.
8.Wipethedipstickcleanwithacleancloth.
9.Insertthedipstickintotheoil-lltube,then
removethedipstick.
23

Toro 20334 Specifications

General

Brand	Toro
Model	20334
Category	Lawn Mower
Power Source	Gasoline
Engine	Briggs & Stratton
Engine Displacement	163 cc
Engine Type	4-Cycle
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Deck Material	Steel
Weight	80 lbs
Start Type	Recoil
Oil Capacity	20 oz
Cutting Width	22 inches
Drive System	Rear-Wheel Drive
Fuel Capacity	1.0 quart
Wheel Size	10 inches rear
Warranty	2-Year Full Warranty
Cutting Height	1.0 to 4.0 inches
