CAUTION
Achildoruntrainedbystandercouldattemptto
operatethetractionunitandbeinjured.
Removethekeyfromtheswitchwhenleaving
thetractionunit,evenifjustforafewseconds.
MovingaNon-functioning
TractionUnit
Important:Donottoworpullthetraction
unitwithoutrstopeningthetowvalves,orthe
hydraulicsystemwillbedamaged.
1.Stoptheengine.
2.Removetheplugcoveringeachtowvalve,located
undereachfueltank(
Figure18).
Figure18
1.Towvalve2.Plug
3.Loosenthejamnutoneachtowvalve.
4.Turneachvalvecounterclockwiseoneturnwitha
hexwrenchtoopenthem.
5.Towthetractionunitasrequired.
Important:Donotexceed3mphwhentowing.
6.Whenyouhaverepairedthetractionunit,closethe
towvalvesandtightenthejamnuts.
Important:Donotovertightenthetowvalves.
7.Replacetheplugs.
UsingtheCylinderLocks
WARNING
Theloaderarmsmaylowerwhenintheraised
positioncrushinganyoneunderthem.
Installthecylinderlocksbeforeperforming
maintenancethatrequiresraisedloaderarms.
InstallingtheCylinderLocks
1.Starttheengine.
2.Raisetheloaderarmstothefullyraisedposition.
3.Stoptheengine.
4.Positionaloaderarmcylinderlockovereachlift
cylinderrod(
Figure19).
5.Secureeachloaderarmcylinderlockwithaclevis
pinandcotterpin(Figure19).
Figure19
1.Cylinderlock4.Clevispin
2.Liftcylinder5.Liftcylinderrod
3.Hairpincotter
6.Withtheengineoff,lowertheloaderarms.
Removing/StoringtheCylinderLock
1.Starttheengine.
2.Raisetheloaderarmstothefullyraisedposition.
3.Stoptheengine.
4.Removetheclevispinandcotterpinsecuringeach
cylinderlock.
5.Removethecylinderlocks.
6.Lowertheloaderarms.
7.Installthecylinderlocksoverthehydraulichoses
andsecurethemwiththeclevispinsandcotterpins
(Figure20).
22
