CAUTION
Thespringisundertensionwhen
installedandcancausepersonalinjury.
Wearsafetyglassesandbecarefulwhen
removingthespring.
7.Removethedeckbeltfromtheclutchandclutch
stop(Figure71).
8.Installthenewbelt.
9.Installthetensionspringandlowerhydraulic
hose.
10.Installthedrainplugsandtorqueto22to27
N∙m(16to20ft-lb).
11.Addhydraulicuidtothelllevel.
12.Installthehydraulic-reservoircap.
13.Runthemachinefor10minutesandverifythat
thehydraulicuidisatthecorrectlevel.
ControlsSystem
Maintenance
Adjustingthe
Motion-ControlLevers
Ifthemotion-controlleversdonotalignhorizontally,
adjustthemotion-controllevers.
1.Parkthemachineonalevelsurface,disengage
thePTO,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Pushthemotion-controlleversdownoutofthe
NEUTRAL-LOCKposition(Figure72).
4.Checkiftherightmotion-controlleveraligns
horizontallywiththeleftmotion-controllever
(Figure72).
g009436
Figure72
1.Leftmotion-controllever3.Checkthehorizontal
alignmenthere
2.Rightmotion-controllever
intheNeutral-lockposition
4.Rightmotion-controllever
Note:Toadjusttherightmotion-controllever
horizontally,adjustthecam.
5.Releasethecushionfromtherearofthe
machine.
6.Loosenthenutholdingthecam(Figure73).
48
