Installingthe
Production-YearDecal
CEMachinesOnly
Partsneededforthisprocedure:
1Production-yeardecal
Procedure
Ifyouusethismachineinacountrythatcompliesto
CEstandards,applytheproduction-yeardecalnear
theserialplate;refertoFigure11.
g233866
Figure11
1.Serialplate
2.Production-yeardecal
7
InstallingtheGrassBasket
Partsneededforthisprocedure:
1
Grassbasket
Procedure
1.Graspthebasketbythehandle.
2.Guidethebasketlipbetweenthecuttingunit
sideplatesandoverthefrontroller(Figure12).
g032407
Figure12
1.Baskethooks
3.Installthebaskethooksovertheframeloop
(Figure12).
Important:Ifyoueverdropthebasket,examine
thepitch-armcontactpointsnearthelowerlip
ofthebasketfordamage(Figure13).Straighten
thembeforeusingthebasket.
Usingthebasketwithbentpitch-armcontact
pointsmaycausecontactbetweenthebasket
andcuttingunit,causingundesirednoiseand/or
damagetothebasketandcuttingunit.
g032408
Figure13
1.Pitch-armcontactpoint
