g279746
Figure8
1.Lockingpin3.Hitchpedal
2.Latch
7.Steponthehitchpedaluntilthehitchlocksinto
place(Figure8).
8.Insertthelockingpinthroughtheholesinthe
latch(Figure8).
9.Torquethelugnutsonthetransportwheelsto
108N∙m(80ft-lb).
3
RemovingtheMachine
fromthePallet
NoPartsRequired
Procedure
1.Removethewoodblocksatthehitchendofthe
pallet.
g024330
Figure9
1.Woodblocks
2.Placesomewoodboardsonthegroundatthe
endofthepallet.
Note:Theheightofthewoodboardsshouldbe
slightlylowerthanthepallet.Youcanusepieces
removedfromthesidesand/orendsofthecrate.
3.Carefullyrollthemachineoffthepallet,ontothe
woodboards,andthentotheground.
Important:Ensurethattherollersdonot
contactthepalletasthemachinedropsto
theground.
4.Removeanyremainingpackaging.
4
LubricatingtheMachine
Partsneededforthisprocedure:
–
Lubricants(notincluded)
Procedure
Beforeyouoperatethemachine,lubricateittoensure
properoperatingcharacteristics;refertoLubricating
theDrive-RollerBearing(page23).Failuretoproperly
lubricatethemachinewillresultinprematurefailure
ofcriticalparts.
10
