Toro GreensPro 1260 User Manual

ProductOverview
g279748
Figure10
1.Hitch-locklever7.Motionpedals
2.Hitchlatch8.Tilt-steeringpedal
3.Seat-adjustmentlever
9.Hourmeter
4.Parkingbrake10.Latchlever
5.Steeringwheel
11.Hitchpedal
6.Lightswitch12.Hitchassembly
g019903
Figure11
1.Sparkplug
4.Recoilstarter
2.Mufer
5.Recoil-starthandle
3.Aircleaner
Controls
ParkingBrake
Engagetheparkingbraketoallowthemachineto
start.T oengagetheparkingbrake(Figure12),pull
backontheparking-brakelever.Todisengageit,
pushtheleverforward.
g027608
Figure12
1.Parking
brake—disengaged
2.Parkingbrake—engaged
SteeringWheel
Turnthesteeringwheel(Figure10)clockwisetoturn
themachineintheforwarddirection.
Turnthesteeringwheelcounterclockwisetoturnthe
machineintherearwarddirection.
Note:Asthedirectionchangesattheendofevery
run,youwillneedtopracticewiththemachineto
becomeaccustomedtothesteering.
Thesteeringwheelcontrolstheangleofthesmoothing
rollers,whichinturnsteerthemachine.Theamount
thewheelcanbeturnedislimited,sotheturning
radiusofthemachineislarge.
Tilt-SteeringPedal
Totiltthesteeringwheeltowardyou,pressthefoot
pedal(Figure10)down,pullthesteeringtowertoward
youtothemostcomfortableposition,andreleasethe
pedal.
MotionPedals
Thefoot-operatedmotionpedals(Figure10),located
toeithersideofthebaseofthesteeringwheel,
controlthemotionofthedriveroller.Thepedalsare
connectedsothattheycannotbothbepresseddown
atthesametime,youcanpressonly1pedalata
11
