14
Engine Governor – Zero Point Setting
1. Loosen but do not remove the governor arm pinch bolt and nut.
2. Move the governor arm to fully open the throttle valve. Firmly hold the governor arm in this position.
3. Rotate the governor shaft fully clockwise and secure it in this position with a pair of pliers.
4. Tighten the governor arm pinch bolt and nut to specification - 7.5 ft-lbs (10 Nm).
5. Verify that the governor arm and throttle valve move freely.
