ConnectingtheBattery
NoPartsRequired
Procedure
WARNING
Electricalsparkscancausethebatterygasses
toexplode,resultinginpersonalinjury.
Incorrectbatterycableroutingcoulddamage
thesprayerandcablescausingsparks.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
Batteryterminalsormetaltoolscouldshort
againstmetalsprayercomponentscausing
sparks.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthesprayer.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsof
thesprayer.
•Alwayskeepthebatterystrapinplaceto
protectandsecurethebattery.
1.Connectthepositivebatterycabletothepositive
postofthebattery(Figure68).
g207211
Figure68
1.Batterycover4.Negativebatterypost
2.Positivebatterycable5.Negativebatterycable
3.Positivebatterypost
2.Connectthenegativebatterycabletothe
negativepostofthebattery(Figure68).
3.Alignthebatterycovertothebatteryboxand
securethecoverwiththestrap(Figure68).
