Toro Pro Control XP User Manual

ProductOverview
G0 13881
1
2
3
4
5
6 7
Figure8
1.Powerswitch
5.CEkey
2.Display6.Functionkeys
3.Calibrationkeys
7.Enterkey
4.Flowcontrolswitch
Controls
TheProControl
™
Systemconsistsofacomputer-based
controlconsole,aspeedsensor,andaturbine-type
owmeter.
Becomefamiliarwiththecontrols(Figure8)beforeyou
starttheengineandoperatethesprayer.
Powerswitch
Thisswitchturnstheconsolepoweronandoff.Turning
offtheconsolecomputerdoesnotaffectthedatastored
inthecomputer.
Flowcontrolswitch
Thisswitchallowsyoutoautomaticallyormanually
controlthespraysystem.Thereare2automatic
positionsand1manualposition.
Display
Thedisplayshowsthefunctionandcalibrationdata.
Calibrationkeys
Thesekeysallowtheoperatortoenterdataintothe
consolecomputertocalibratethespraysystem.
Functionkeys
Thesekeysdisplayneededdata,suchasthetotalarea
sprayed,thetotalvolumeofmaterialsprayed,thevehicle
speed,andthevolumeofmaterialremaininginthetank.
Enterkey
Thiskeyallowsyoutoenterdataintotheconsole
computer.
CEkey
Thiskeyclearsthedatashowninthedisplay;italso
enablesyoutotogglethroughtheoptionsfoundin
certainfunctionkeys.
Theconsolecomputerallowsthefollowingparameters:
Area:US(acres);SI(hectares)orTU(1000ft
2
).
TheConsolekeys
ThekeypadfortheconsolecomputerisshowninFigureFigure9.
G013305
BOOM 1
CAL
1
BOOM 2
CAL
2
BOOM 3
CAL
3
SPEED
CAL
4
METER
CAL
5
VALVE
CAL
6
RATE 1
CAL
7
RATE 2
CAL
8
VOL
TANK
9
TIME
0
SELF
TEST
CE
TOTAL
AREA
TOTAL
VOLUME
FIELD
AREA VOLUME
FIELD
DISTANCE
SPEED
MIN
VOL /
HOUR
AREA /
MENU
DATA
ENTER
Figure9
7
