g007330
Figure16
1.Rollerscraper2.Nut
2.Slidetherollerscraperinoroutuntiltherequired
positionisattained,andtightenthefasteners.
3.OntheProCore864only,youcanadjustthe
stopboltonthecentersupporttoattainthe
propergap.
8
InstallingtheTineHeads
andtheTines
NoPartsRequired
Procedure
Awideselectionoftinesandtineheadsareavailable
forthemachine.Choosethetinetype,size,and
spacingsrequiredforthejob.Installthetineheadand
tinespertheInstallationInstructionssuppliedwith
eachtinekit;refertoProCore864tineconguration
tableandProCore1298tinecongurationtablein
Attachments/Accessories(page17).
Important:Neveroperatethemachinewithout
thetineheadsinstalled.Thearmsmaymove
excessivelyanddamagetheframeofthemachine.
9
InstallingtheTurfGuards
Partsneededforthisprocedure:
–
Turfguards(notincluded)
Procedure
Awideselectionofturfguardsisavailableforthe
machine.Usetheappropriateturfguardsforthe
selectedtineheads.
1.Loosenthenutssecuringtheturfguardclamps
totheturfguardtoolbar(Figure17).
g007331
Figure17
1.Turfguard2.Turfguardclamp
2.Slidetheappropriateturfguardundertheturf
guardclamp.
3.Adjusttheturfguards,lefttoright,tomaintain
equaldistancetothetineswithineachslot.
4.Tightenthenutssecuringtheturfguard.
5.Mounttheremainingturfguardsandsecurethe
turfguardclamps.
Important:Fromtherearofthemachine,
checkthatthetineslineupwiththecenterof
thegapsintheturfguards.
