Figure42
RemovingtheMachine
fromtheTractionUnit
Important:RefertothePTOdriveshaftowner’s
manualforadditionaloperatingandsafety
information.
1.Parkthetractionunitandmachineonalevel
surface,disengagethePTO,engagetheparking
brake,shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleaving
theoperator'sseat.
2.Installthestoragestandsandsecurethemto
themachinewiththelynchpins(Figure43).
g007302
Figure43
1.Lynchpins
2.Storagestand
Note:Youcanstorethemachineontheoriginal
shippingpallet.
3.Slowlylowerthemachineuntilthestorage
standscontacttheground.
4.Loosenthelockingnutandrotatetheupper
adjustinglinktoreleasethetensionbetweenthe
machineandthetractionunit.
5.Removethelynchpinandthetoplinkpin
securingthecenterlinktothebracket.Retain
thelynchpinandthetoplinkpinwiththe
machine.
6.Disconnectthesafetyshieldchainsfromthe
tractionunitPTO(CEonly).
7.Pullbackonthelockcollartodisconnectthe
PTOdriveshaftfromthePTOoutputshafton
thetractionunit.
8.SlidethePTOdriveshaftbackandremoveit
fromthetractionunit.
9.SupportthePTOdriveshaftbyconnectingthe
PTOtethertothePTOshieldtopreventthe
driveshaftfromcontactingtheground(Figure
44).
