10
SecuringtheHoodLatches
(CEonly)
Partsneededforthisprocedure:
1
CEComplianceKit,PartNo.110-4693(notincluded)
Procedure
Note:TheCECompletionKit,PartNo.110-4693is
requiredtocompletethisstep.
1.OntheProCore864model,installalockbracket
overtheleftandrightrearlowerhoodandupper
hoodlatcheswithatapbolt(4total);referto
Figure18.
g007299
Figure18
1.Tapbolt3.Internallockwasher
2.Lockbracket4.Rearcover
2.OntheProCore1298model,installalock
bracketoveralltherearlowerhoodlatchesand
theoutsideupperhoodlatchonboththeright
andtheleftrearcoverswithatapbolt(3per
coringhead,6total);refertoFigure18).
3.Usingapliersoradjustablewrench,thread
aninternallockwasherontoeachbolt(1to2
threads)tosecurethelatch(Figure18).
11
ApplyingtheEntanglement
Decal
CEMowers
Partsneededforthisprocedure:
4
CEentanglementdecal
Procedure
Important:ThisprocedureisrequiredforallCE
countriesandanywhereEnglishisnotcommonly
spoken.
1.Rotatetheshaftguardtoaccesstheexisting
entanglementdecal(Figure19).
g273731
Figure19
1.Existingentanglement
decal
2.CEentanglementdecal
2.Cleantheexistingentanglementdecalandthe
guardareasurroundingthedecal.
3.RemovethebackingfromtheCEentanglement
decal.
15
