Toro TimeCutter SS 4250 User Manual

g005192
Figure60
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grass-deectorbracket7.Shortstandoff
4.Rod
2.Slidetherodoutoftheshortstandoff,spring,
andgrassdeector(Figure60).
3.Removethedamagedorworngrassdeector.
4.Replacethegrassdeector(Figure60).
5.Slidetherod(straightend),throughtherear
grass-deectorbracket.
6.Placethespringontherod,withtheendwires
downandbetweenthegrass-deectorbrackets.
7.Sliderodthroughthesecondgrass-deector
bracket(Figure60).
8.Inserttherodatthefrontofthegrassdeector
intotheshortstandoffonthedeck.
9.Securetherearendoftherodintothemower
withanut(3/8inch)asshowninFigure60.
Important:Thegrassdeectormustbe
spring-loadedandinthedownposition.Lift
thedeectoruptotestthatitsnapstothe
fulldownposition.
MowerBeltMaintenance
InspectingtheBelts
ServiceInterval:Every25hours—Checkthebelts
forwearorcracks.
Checkthebeltsforcracks,frayededges,burnmarks,
oranyotherdamage.Replacedamagedbelts.
ReplacingtheMowerBelt
Thesignsofawornbeltincludesquealingwhilethe
beltisrotating,bladesslippingwhilecuttinggrass,
andfrayededges,burnmarks,andcracksonthebelt.
Replacethemowerbeltifanyoftheseconditionsare
evident.
1.Parkthemachineonalevelsurfaceand
disengagetheblade-controlswitch.
2.Movethemotion-controlleversoutwardtothe
PARKposition,shutofftheengine,removethe
key,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Settheheight-of-cutatthelowestcutting
positionof38mm(1-1/2inches).
4.Removethepulleycovers(Figure61).
g032555
Figure61
1.Cover2.Screw
5.Usingaspring-removaltool(T oroPartNo.
92-5771),removetheidlerspringfromthedeck
hooktoremovetensionontheidlerpulley,and
rollthebeltoffthepulleys(Figure62).
WARNING
Thespringisundertensionwhen
installedandcancausepersonalinjury.
Becarefulwhenremovingthebelt.
6.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure62).
47
