ProductOverview
g027829
Figure5
1.Height-of-cutlever
5.Mowerdeck9.Fuel-tankcap13.Reardrivewheel
2.Motion-controllevers6.Anti-scalproller10.Engine14.Engineguard
3.Operatorseat
7.Frontcasterwheels
11.Controlpanel
4.SmartSpeed™lever
8.Footrest
12.Deector
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g032603
Figure6
1.Throttlecontrol3.Blade-controlswitch
(powertakeoff)
2.Chokecontrol
4.Keyswitch
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page28).
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure6).
ChokeControl
Usethechokecontroltostartacoldengine.
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure6).
