Toro timecutter zs 4200t User Manual

Pre-Maintenance
Procedures
RaisingtheSeat
Ensurethattheparkingbrakeisengaged.Liftthe
seatforward.
Youcanaccessfollowingcomponentsbyraisingthe
seat:
•Serialplate
•Servicedecal
•Seat-adjustmentbolts(ifapplicable)
•Fuellter
•Batteryandbatterycables
ReleasingtheMower-Deck
Curtain
Loosenthe2bottomboltsofthecurtaintoaccessthe
topofthemowerdeck(Figure37).
g027794
Figure37
1.Bottombolt
2.Curtain
Note:Alwaystightentheboltstoconnectthecurtain
aftermaintenance.
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseallthe
lubricationpoints.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake;refertoParkPosition(page16).
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettings(Figure38andFigure
39)witharag.
Note:Scrapeanypaintoffthefrontofthe
tting(s).
g032432
Figure38
1.Frontcastertire
decal106-8717
Figure39
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance
3.Greaseevery25operating
hours
2.Checkthetirepressure
every25operatinghours
4.Engine
4.Connectagreaseguntoeachtting(Figure38
andFigure39).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
6.Wipeupanyexcessgrease.
39
