Toro TITAN ZX 5400 User Manual

Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure5).
g017722
1
2
3
4
5
Figure5
1.Throttlecontrol4.Ignitionswitch
2.Choke
5.Blade-controlswitch
(PTO)
3.Hourmeter
IgnitionSwitch
Theignitionswitchhas3positions:START,RUN,andOFF..
ThekeywillturntotheSTARTpositionandmovebackto
theRUNpositionuponrelease.TurningthekeytotheOFF
positionwillshutofftheengine;however,alwaysremovethe
keywhenleavingthemachinetopreventtheenginefrom
accidentallystarting(Figure5).
ThrottleControl
ThethrottlecontrolisvariablebetweentheFASTandSLOW
position.Movingthrottleleverforwardincreasesengine
speedandmovingthrottlelevertothereardecreasesengine
speed.Movingthethrottleforwardintothedetentisfull
throttle(Figure5).
Choke
Usethechoketostartacoldengine.Pullthechokeknobup
toengageit.Pushdownonthechokeknobtodisengageit.
BladeControlSwitch(PowerTakeoff)
Theblade-controlswitchengagesanddisengagespowerto
themowerblades(Figure5).
HourMeter
Thehourmeterrecordsthenumberofhourstheblades
operate.Itoperateswhentheblade-controlswitch(PTO)is
engaged.Usethesetimesforschedulingregularmaintenance
(Figure5).
FuelGauge
Thefuelwindowlocatedbelowtheoperatorpositioncanbe
usedtoverifythelevelofgasolineinthetank(Figure6).
g020264
1
Figure6
1.Fuel-gaugewindow
Motion-ControlLevers
Themotion-controlleversarespeed-sensitivecontrolsof
independent-wheelmotors.Movingaleverforwardor
backwardturnsthewheelonthesamesideforwardor
inreverse;wheelspeedisproportionaltotheamountthe
leverismoved.Movethecontrolleversoutwardfromthe
centertotheNEUTRAL-LOCKpositionandexitthemachine
(Figure4).Alwayspositionthemotion-controlleversinto
theNEUTRAL-LOCKpositionwhenyoustopthemachine
orleaveitunattended.
Parking-BrakeLever
Theparking-brakeleverislocatedonleftsideoftheconsole
(Figure4).Thebrakeleverengagesaparkingbrakeonthe
drivewheels.Pulltheleverupandrearwardtoengagethe
brake.Pushtheleverforwardanddowntodisengagethe
brake.
FootPedalDeck-LiftSystem
Thefootpedaldeck-liftsystemallowstheoperatortolower
andraisethedeckfromtheseatedposition.Theoperatorcan
usethefootpedaltoliftthedeckbrieytoavoidobstacles
orlockthedeckinthehighestheightofcutortransport
position(Figure4).
Height-of-CutLever
Theheight-of-cutleverworkswiththefootpedaltolockthe
deckinaspeciccuttingheight.Onlyadjusttheheightofcut
whilemachineisnotmoving(Figure4).
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww .Toro.comforalistofallapproved
attachmentsandaccessories.
15
