Figure70
1.Bladesfronttorear3.Measurefromthetipofthe
bladetotheatsurface
here.
2.Outsidecuttingedges
LevelingtheMowerDeck
1.Setanti-scalprollerstotopholesorremovethem
completelyforthisprocedure;refertoAdjustingthe
Anti-ScalpRollers(page24).
2.Settheheight-of-cutlevertothe76mm(3inch)
position;refertoAdjustingtheHeightofCut(page23).
3.Place26.6cm(2-5/8inches)blocksundereachsideof
thefrontedgeofthedeck,butnotundertheanti-scalp
rollerbrackets(Figure71).
4.Place27.3cm(2-7/8inches)thickblocksunderthe
rearedgeofthecuttingdeckskirt;oneoneachsideof
thecuttingdeck(Figure71).
Figure71
1.Woodblock—6.6cm
(2-5/8inches)thick
3.Frontedge
2.Woodblock—7.3cm
(2-7/8inches)thick
5.Loosentheadjustmentboltsonall4cornerssothat
thedeckissittingsecurelyonall4blocks(Figure72).
Figure72
1.Deck-liftarm
3.Hook
2.Chain
4.Adjustmentbolt
6.Ensurethatthereistensiononall4chains(Figure72).
7.Tightenthe4adjustmentbolts(Figure72).
8.Ensurethattheblockstsnuglyunderthedeckskirt
andthatallboltsaretight.
9.Verifythatthedeckislevelbycheckingtheside-to-side
levelandfront-to-rearbladeslope;repeatthedeck
levelingprocedureifnecessary.
InspectingtheBelts
ServiceInterval:Every50hours
Checkthebeltsforsquealingwhenthebeltisrotating,blades
slippingwhencuttinggrass,frayedbeltedges,burnmarksand
cracksaresignsofawornmowerbelt.Replacethemower
beltifanyoftheseconditionsareevident.
