g024410
1
2
3
4
Figure23
1.Deck-liftpedal3.Height-of-cutpositions
2.Handle4.Pin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheightofcut,itisrecommendedto
adjusttheheightoftheanti-scalprollers.
1.Disengagetheblade-controlswitch(PTO),movethe
motion-controlleverstotheNEUTRAL-LOCKposition,
andsettheparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removetheangenut,anti-scalproller,andboltfrom
thebracket(Figure24).
Note:Keeptheboltandanti-scalprollertogether
whenremoving.
g024312
1
2 3 4
5
Figure24
1.Flangenut4.Bushing
2.Spacer
5.Bolt
3.Anti-scalproller
4.Aligntheboltandanti-scalprollerintheholeofthe
bracketthatmatchedtheclosestheight-of-cutposition
(Figure24).
5.Inserttheboltintothebracketholeandsecurethebolt
andanti-scalprollerwiththeangenut(Figure24).
PositioningtheSeat
Theseatcanmoveforwardandbackward(Figure25).
Positiontheseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable.
Figure25
AdjustingtheMotion-Control
Levers
AdjustingtheHeight
Note:Repeattheadjustmentfortheoppositecontrollever.
Themotion-controlleverscanbeadjustedhigherorlowerfor
maximumoperatorcomfort(Figure26).
g027252
B
A
Figure26
24
