AdjustingtheTilt
Themotion-controlleverscanbetiltedforwardorrearward
formaximumoperatorcomfort.
1.Loosentheupperboltholdingthecontrollevertothe
control-armshaft.
2.Loosenthelowerboltjustenoughtopivotthecontrol
leverforwardorrearward.
3.Tightenbothboltstosecurethecontrolinthenew
position.
4.Repeattheadjustmentfortheoppositecontrollever.
PushingtheMachinebyHand
Important:Alwayspushthemachinebyhand.Never
towthemachinebecausedamagemayoccur.
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrolswitch.
2.Movethemotioncontrolleversoutwardtoneutrallock
position,shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingtheoperating
position.Makesuretheparkingbrakeisdisengaged.
3.DothisprocedureoneachsideofthemachineFigure
27.
BA
DC
g027642
Figure27
4.Movethebypasstothepositionforoperatingthe
machine(Figure27)toengagethewheelmotors.
Convertingthe48-InchMower
toSideDischarge
Themowerdeckandmowerbladesshippedwiththismachine
weredesignedforoptimummulchingandside-discharge
performance.
Installthefastenersintothesameholesinthedeckthatthey
wereoriginallyremovedfrom.Thisensurenoholesareleft
openwhenthedeckisoperated.
DANGER
Openholesinthemowerexposeyouandothersto
throwndebris.Debristhrownoutofholesinthe
mowercancauseinjury.
•Neveroperatethemowerwithouthardware
mountedinallholesinthemower.
•Installhardwareinmountingholeswhenthe
bafeisremoved.
RemovingtheMulchingBafe
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Movethemotion-controlleversoutwardtothe
NEUTRAL-LOCKposition,settheparkingbrake,shut
offtheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Removethemower;refertoRemovingtheMower
(page48).
4.Turnthemowerupsidedown.
5.Removethe2locknuts(5/16inch)securedtothe
weldedpostsoftheleftbafeonthetopofthemower
deckatthecenterandleftofcenterpositions(Figure
28).
1
1
2
3
G012841
Figure28
1.Locknut(5/16inch)3.Leftbafe
2.Carriagebolt(5/16x3/4
inch)
6.Removethecarriageboltandlocknutonthesidewall
ofthemowerdecksecuringtheleftbafetothedeck.
25
