17
Signal Strength Display
This feature displays sensor signal strength on a digital scale ranging from 0.0 to 10.2
1. Press the Setup button as needed to display the antenna icon and the
digital readout. The display will indicate the strength of the last received
signal. See Figure 22.
Important: A signal strength value less than 2.0 is not reliable and
may cause inconsistent operation. Relocate the sensor as needed to
increase the signal strength. Refer to “Resolving Reception Problems”
on page 22 for additional information.
Battery Strength Display
This feature displays sensor battery strength on a bar scale. The strength of the battery is indicated
by the height of the bar stack: No bar = a dead battery to six bars = full strength.
1. Press the Setup button as needed to display the battery symbol and
the bar scale. See Figure 23.
Note: Low battery strength is indicated when the battery symbol appears
on the main display. To prevent possible loss of communication, battery
replacement is recommended.
Refer to “Sensor Module Battery Replacement” on page 21.
Figure 22
Figure 23
